Geelong veneer patching machine, has so many models, we have semi automatic model, have automatic model, has the hydraulic veneer patcher, also has the pneumatic veneer paching machine, we can make the veneer patching machine according to clients requirements, like your veneer barks, holes, shortcomings size information. after veneer patching machine, the bad veneers can become to good veneers, the quality of the plywood will be improved a lots. welcome to inquiry geelong brand china veneer patching machine. Buy good quality plywood machine, select geelong machinery company.
technical parameters of veneer patching machine：
| Product name | Veneer patching machine(equipped with male and female mold) |
| Product model | GLVPM-788-6 |
| Applicable veneer thickness | Max. 4mm thickness veneer(based on poplar) |
| Applicable veneer size | 1270x1270, or 1270x2560mmWorking table can be designed according to the veneer size |
| Working principle | Air cylinder control(big mould equipped supercharged cylinder) |
| Controlling methods | Foot switch control |
| Working air pressure | 0.5-0.7MPA |
| Working power | Less than 0.3KW |
| Working power volts | AC220V-50Hz |
| Mold size | 100x200mm, 350x160mm, 350x50mmMolding size can be designed according to the barks of veneers, big mold and small mold adopt standard cost |
| Machine frame | It is welded by profile and steel plate, and it is welded by national standard channel steel + reinforcing rib |
| Machine beam | Both the upper and lower beams are ground and processed using milling machines with high precision. |
| Repairing table | High-quality poplar eucalyptus plywood edge banding process |
| Machine quality guarantee | Whole machine one year guarantee |
| Machine dimension(length X width X height) | 3720x1310x1860mm |
| Machine weight | Approx.2000kgs |
this model veneer patching machine, is designed and produced by SHANDONG GEELONG MACHINERY, in this machine, you can set three size holes for punch the veneers, max thickness: 4mm, three for punch the bad area veneers, another three can punch the fresh good veneers then fullfilled holes with good veneers. our veneer patcher machine can be applicable for soft wood and hard wood veneers, you can inform us your inquiry request according to your veneers barks hole information.
This is manual veneer patching machine, if you need automatic veneer patching machine, we also have, we have two models, one is hydraulic motivated, another one is pneumatic, if you are needing automatic veneer patching machine, welcome to inquiry.
